High-Precision Automatic Flute Laminator Machine (DX-1650)

Direct Factory Manufacturer | Servo Registration | Real-Time Glue Recirculation

The DX-1650 Flute Laminator is engineered for high-graphic packaging manufacturers, corrugated box plants, and commercial printers. It seamlessly bonds printed cardboard sheets (120–600 gsm) with single-face or multi-ply corrugated board (0.5–10 mm) at production speeds up to 150 m/min.

Instead of relying solely on high nominal speed, our DX-1650 focuses on real-world yield: eliminating double-feeding, preventing glue overflow, and maintaining precise ±1 mm registration on warped or uneven substrates.

Multi Ply Cardboard Flute Laminator
The DX-1450 is a high-performance flute laminating machine designed for modern printing and packaging factories that require stable production, high accuracy, and continuous high-speed operation.
Front Feeder Litho Flute Laminator Machine
Packaging Details:Meteorological anti-rust film and steel bottom bracket. Delivery Time:60 DAYS. Payment Terms:L/C, D/A, D/P, T/T. Supply Ability:5 SET/MONTH
Cardboard High Speed Flute Laminator
The DX-1650 is a high-speed, industrial-grade sheet-to-cardboard flute laminator designed for modern printing and packaging factories that require precision, efficiency, and long-term reliability.
Flute Lamination Pasting Machine
The DF-1450S Automatic Flute Laminator is a high-precision, fully automated lamination machine designed for modern printing and packaging production. Engineered for stability, accuracy, and long-term
5 Layers Double Wall Flute Laminator Machine
The DF-1450S Automatic Flute Laminator is a professional-grade, fully automated lamination machine designed for modern printing and packaging factories. Unlike standard laminators, the DF-1450S
Corrugated Paperboard Laminating Machine
Unlike high-speed laminators that demand strict material conditions and highly skilled operators, the DF-1650EL focuses on practical performance in real factory environments. It delivers reliable
Rowan Series Flute Laminator Machine
The DF-1450S Chain Leading Register Laminator from the Rowan Series is a reinforced, high-precision laminating machine developed for packaging and printing factories that require stable feeding,

Key Components & Supply Chain Partners

To ensure 24/7 continuous operational stability and zero unscheduled downtime, we build the DX-1650 using heavy-duty cast-iron frames and globally recognized components:

Motion Control & PLC	Siemens / Schneider Electric
Servo Drives	Yaskawa / Panasonic
Pneumatics & Glue Stopper	Festo / SMC
Photoelectric & Optical Sensors	Sick / Banner
Bearings & Drives	NSK / SKF

Solved: Common Bottlenecks in Corrugated

Operational Challenge	Traditional / Manual Laminators	DX-1650 Servo Solution	Operational Benefit
Sheet Misalignment	Manual mechanical stops causing ±3mm variance	Sensor detection + Independent Servo compensation	Reduces scrap rates; ensures perfect alignment for downstream die-cutting
Warped Board Feeding	Frequent jams, double-feeds, and operator stops	Vacuum suction belt + Dual-servo bottom feeding	Smooth feeding of 0.5–10mm single-face, multi-ply, and grey boards
Excessive Glue Usage	Manual roll adjustments lead to glue squeeze-out and board warping	Precision metering rollers + Automatic level sensor + Recirculation	Up to 20% reduction in adhesive consumption; prevents board sogginess
Frequent Order Swaps	20–30 minutes of manual setup per job change	Centralized HMI memory storing recipe parameters	Fast job changeovers in under 5 minutes for small-batch runs

Works: Step-by-Step Precision Integration

Servo Shaftless Top Sheet Feeding
Processes printed sheets from 120 to 600 gsm. The shaftless feeder prevents surface scuffing on delicate high-gloss or laminated prints while maintaining overlapping sheet control.

Dual-Servo Bottom Board Feeding
Independent servo-driven suction belts handle warped, heavy, or multi-ply corrugated boards without mechanical friction damage.

Automatic Dynamic Registration (±1 mm Accuracy)
High-speed optical sensors detect the leading edge of both top and bottom sheets in real time. Servo motors calculate the offset and instantly adjust the sheet position prior to pressing.

Closed-Loop Glue Application System
Includes side glue stoppers, continuous level monitoring, and an automatic recirculation pump. Keeps adhesive distribution uniform across the entire sheet width while reclaiming unused glue.

Speed-Synchronized Pressing Conveyor
The pressing belt speed automatically syncs with the laminating section to ensure uniform pressure during initial adhesive tack, preventing sheet shifting before curing.

rowan-series-flute-laminator-machinec10d5

Technical Specifications

Parameter	Specification / Capability
Model	DX-1650
Max. Mechanical Speed	Up to 150 m/min
Max. Hourly Output	Up to 12,000 sheets/hour (at 600 mm sheet length)
Top Sheet Weight	120 - 600 gsm
Bottom Board Range	0.5 - 10 mm (Single-face, 3-ply, 5-ply, Greyboard)
Registration Accuracy	Approx. ±1 mm
Feeding Mechanism	Servo-driven Top & Bottom Feeders
Control Architecture	PLC + Touchscreen HMI
Material Loading	Low-position pile loader with optional rail pre-loader

Machine Selection & Production Matching

For High-Volume Micro-Flute Cartons (E/F/G Flute)

Standard DX-1650 configuration with precision metering rolls to avoid board crushing.

For Heavy-Duty Shipping Containers (A/B/C Flute, 5-Ply)

Reinforced dual-servo bottom feeder with extended pressing conveyor for longer curing time.

For High-Graphic Display Stands (Greyboard Lamination)

Optional heavy-duty feeder modules for thick paperboard substrates.

For Short-Run Custom Packaging

Integrated HMI order memory system for rapid dimensions setup.

Pre-Shipment Inspection & Factory Acceptance Testing

We do not ship machines based on theoretical parameters. Every DX-1650 undergoes a rigorous pre-delivery validation:

Structural & Frame Alignment Check

Laser measurement of roller parallelism and chassis rigidity.

48-Hour Continuous Dry-Cycle Run

Stress-testing electrical panels, PLC routines, and pneumatic valves.

Customer Material FAT (Factory Acceptance Test)

We run your specific paper gsm, flute profiles, and adhesives at target operational speeds to verify registration accuracy (±1 mm) and bonding strength before crating.

Shipping&Delivery

Request a Machine Recommendation & Trial Run

Get an exact equipment configuration tailored to your sheet format, board plies, and hourly target output.
Please share your production parameters:
Top Sheet GSM Range & Max/Min Dimensions
Corrugated Flute Types (E.g., E, B, C, EB Flute)
Required Daily or Hourly Output (Sheets/Hour)
Current Adhesive Type Used (PVA / Starch / Other)
[ SUBMIT SPECIFICATIONS FOR A DIRECT FACTORY QUOTE ]

FAQ

Q: What is the minimum and maximum paper size the DX-1650 can handle?

A: The standard DX-1650 handles sheet widths up to 1650 mm. Custom width options (e.g., 1300 mm or 1900 mm) are available upon request based on your plant's die-cutter dimensions.

Q: Can the machine laminate heavy 5-ply corrugated board to thin paper?

A: Yes. The dual-servo bottom feeder adjusts suction strength and feeding speed automatically to handle rigid 5-ply board without causing jam-ups when meeting lightweight 120 gsm printed sheets.

Q: How does the automatic glue recirculation system save operational costs?

A: Adhesive is continuously pumped, metered, and reclaimed via side stoppers. Unused glue returns to the main tank rather than overflowing onto machine side-frames, reducing daily cleaning labor and lowering total glue consumption by 15% to 20%.

Q: Can this laminator be integrated into an automated inline production workflow?

A: Yes. The DX-1650 can be connected directly to upstream flip-flop stackers, automatic turners, or downstream flatbed die-cutters via standardized signal interfaces.
