Product Overview
The RX910 Automatic Honeycomb Paper Sleeve Machine is a professional eco-friendly packaging solution designed for high-value fragile items. Built for efficiency, precision, and sustainability, the RX910 uses 11 servo motors, 3 cylinders, and 2 glue guns to fully automate the production of honeycomb paper sleeves. It is ideal for wine bottles, cosmetics, ceramics, electronics, and other delicate products, serving as a perfect eco-friendly alternative to plastic bubble wrap.
Key Features
Fully Automated Production:
Minimizes manual labor, improves consistency.
Eco-Friendly & Biodegradable:
Uses natural kraft paper and water-based adhesive.
High Efficiency:
13-18 seconds per cycle; multiple products can be produced simultaneously.
Multi-Spec Production:
Adjustable core dimensions for a wide range of product sizes.
Core Specifications
- Production Range:
Maximum effective length: 910 mm
Core height: 8-20 mm
Core width: 8-50 mm
Core length: 50-910 mm
Cell size: 15-40 mm
- Performance:
Production cycle: 13-18 sec/cycle
Output: 4-12 pcs/min (depending on sleeve length)
- System:
Servo motors: 11 units
Cylinders: 3 units
Glue guns: 2 units
Power: 3 kW
Air pressure: 0.6 MPa
Voltage: 220V/380V (optional)
- Paper Compatibility: 50-190 g kraft paper
- Layers: 60-70+ layers
Technical Parameters
|
Feature |
Specification |
|
Model |
RX910 |
|
Effective Length |
80-910 mm |
|
Core Height |
8-20 mm |
|
Core Width |
8-50 mm |
|
Core Length |
50-910 mm |
|
Cell Size |
15-40 mm |
|
Paper Weight |
50-190 g kraft paper |
|
Layers |
60-70+ |
|
Cycle Time |
13-18 sec/cycle |
|
Output |
4-12 pcs/min |
|
Batch Production |
Multiple sleeves simultaneously (e.g., 4×200 mm or 1×900 mm) |
|
Servo Motors |
11 units |
|
Cylinders |
3 units |
|
Glue Guns |
2 units |
|
Glue Type |
Eco-friendly water-based adhesive |
|
Power |
3 kW |
|
Air Pressure |
0.6 MPa |
|
Dimensions |
1850 × 1500 × 1600 mm |
|
Weight |
600 kg |
Working Principle
The RX910 operates through a fully automated 5-step process:
- Feeding: Pre-cut honeycomb cores are placed onto the machine.
- Positioning: 11 servo motors precisely position the cores.
- Gluing: 2 glue guns apply eco-friendly water-based adhesive at bonding points.
- Stretching & Bonding: 3 cylinders stretch and press the cores into 3D honeycomb sleeves.
- Ejection: Finished sleeves are automatically released for collection.
- Cycle Time: 13-18 sec/cycle, batch production of multiple sleeves supported.
Machine Advantages
|
100% Biodegradable & Recyclable |
Natural kraft paper, eco-friendly water glue. |
|
Fully Automated & Efficient |
Replaces 3-5 operators, precise ±1 mm positioning. |
|
Flexible Batch Production |
Handles 910 mm max length, can produce multiple pieces simultaneously. |
|
Plastic-Free Packaging |
Replaces bubble wrap, EPE foam, and inflatable cushions. |
|
Premium Aesthetic |
Honeycomb structure enhances brand image and unboxing experience. |
|
Low Cost & High ROI |
Fast production and low material costs allow ROI within 1-2 months. |
Applicable Products
|
Wine & Liquor |
Red wine, champagne, spirits. |
|
Cosmetics |
Perfumes, serums, makeup kits. |
|
Ceramics & Glass |
Vases, glassware, pottery. |
|
Food & Beverages |
Bottled sauces, organic products, canned goods. |
|
Electronics |
Small components and delicate devices. |
|
Handicrafts & Art Pieces |
Decorative and fragile items. |
|
Agricultural Products |
Fruits, flowers, fresh produce. |
|
Pharmaceuticals |
Medicine bottles, medical supplies. |
|
Gift Packaging |
Premium gift presentation. |
Core Components
- Servo Motor System: 11 units for precise movement and bonding.
- Cylinder Pressing System: 3 cylinders at 0.6 MPa for strong adhesion.
- Automatic Gluing System: 2 glue guns with water-based adhesive.
- Control Panel System: Touchscreen interface for parameter setting and diagnostics.
- Stretching & Forming Mechanism: Forms 3D honeycomb structure.
- Automatic Ejection System: Efficient output of finished sleeves.
Application Scenarios
- Premium Wine & Spirits – protect delicate bottles.
- Luxury Cosmetics – premium packaging for perfumes and skincare.
- E-commerce Logistics – eco-friendly shipping solutions.
- Ceramics & Pottery – safe transport of fragile items.
- Food & Beverage – organic and high-end product packaging.
- Gift Packaging – high-end presentation and protection.
Brand Commitment
- Eco Packaging · Green Future – sustainable solutions for global markets.
- Automation Expertise – specialized in honeycomb sleeve production.
- Environmental Promise: 100% biodegradable, 100% recyclable, water-based adhesive.
- Contact & Support: Phone, email, website.
- CTA: Contact Us Now for More Info
Tagline: Eco-friendly · Efficient · Automated · Sustainable
RX910 Automatic Honeycomb Paper Sleeve Machine – FAQ for Printing & Packaging Businesses
1. Why should I switch from plastic bubble wrap to honeycomb paper sleeves?
Answer: Plastic is increasingly restricted worldwide due to environmental regulations. RX910 produces 100% biodegradable and recyclable honeycomb paper sleeves. This not only helps you comply with global bans on plastic but also positions your company as eco-friendly, attracting environmentally conscious clients.
2. How much can this machine increase my production efficiency?
Answer: RX910 uses 11 servo motors and 3 cylinders to automate feeding, positioning, gluing, stretching, and ejection. Each production cycle takes only 13-18 seconds, producing 4-12 pieces per minute depending on sleeve size. This replaces 3-5 operators and significantly reduces labor costs.
3. What product sizes can it handle?
Answer: The machine is flexible for multi-spec production:
● Core height: 8-20 mm
● Core width: 8-50 mm
● Core length: 50-910 mm
● Cell size: 15-40 mm
This covers wine bottles, cosmetics, ceramics, electronics, and more, all on the same machine.
4. How reliable is the machine? Can it handle large batches?
Answer: RX910 is designed for industrial-scale production. It can produce multiple sleeves simultaneously (e.g., 4×200mm or 1×900mm) with precise ±1 mm tolerance. The servo-controlled system ensures consistent quality and reduces human error, even for long production runs.
5. What are the operational costs compared to traditional methods?
Answer: Honeycomb paper is far cheaper than plastic bubble wrap or EPE foam. The RX910's high automation reduces labor costs. With production speeds of 13-18 seconds per cycle and low material cost, the typical ROI is 1-2 months, depending on your production volume.
6. Is the glue safe and environmentally friendly?
Answer: Yes, RX910 uses water-based eco glue, free from harmful solvents. Combined with natural kraft paper, the entire packaging is 100% biodegradable and recyclable.
7. How easy is it to operate? Do I need specialized staff?
Answer: The machine comes with a touchscreen control panel for simple parameter setting and diagnostics. Operators need minimal training to start production. The system automates feeding, gluing, stretching, and ejection, reducing dependency on skilled labor.
8. Can it replace multiple machines in my production line?
Answer: Absolutely. RX910 combines feeding, positioning, gluing, stretching, and ejection in one unit. You no longer need separate gluing or forming machines. This saves factory space, reduces maintenance, and consolidates workflow.
9. Will this help me attract premium clients?
Answer: Yes. Honeycomb sleeves are visually appealing and enhance the unboxing experience. Many wine, cosmetics, and gift brands prefer eco-friendly, stylish packaging. By offering biodegradable protective sleeves, your business can differentiate itself in competitive markets.
10. What support and after-sales service is available?
Answer: We provide installation guidance, staff training, and ongoing technical support. Replacement parts, maintenance tips, and troubleshooting assistance are included to ensure continuous, worry-free operation.
✅ Summary: RX910 saves labor, reduces costs, increases output, and provides a premium eco-friendly packaging solution. It's perfect for printing and packaging factories looking to upgrade their production lines and align with global environmental trends.
